Lithium battery Afore ATOM 5.12KWh (1 module)

Name: Lithium battery Afore ATOM 5.12KWh (1 module)
Brand: Afore
SKU: 1879
Price: 1171.28 USD
Availability: InStock

$1,171.28

Reference ATOM LS 5.12

The lithium battery Afore ATOM Ls in his version of 1 module (5,12KWh) It is the base unit of the stackable modular system, ideal for self-consumption facilities that seek to start with little capacity and scalar progressively with time according to your needs. Technology-based Lifepo4, it offers a Nominal capacity of 100Ah and one Energy of 5120Wh (5,12kWh), with a Nominal voltage of 51.2V and a range of operating voltage 43.2V to 58.4V. Your Smart BMS Protects against overvoltage, overcurrent, overperforming and short circuits, with an active balancer that prolongs the useful life of the cells. Highlights for a life cycle of up to 6000 cycles 0.5c, one 90% download depth (dod) and one 97% efficiency, with housing Ip65 and corrosion resistance C4 Fit for indoor or exterior.

Category: Lithium batteries Brand: Afore

Description

Benefits of lithium battery Afore ATOM LS 5.12KWh

The main value of this lithium battery modular is the possibility to start with a single module of 5,12kwh and expand the installation later by adding a second or third module, until reaching the 15,36kwh In the same stack, without the need to replace the equipment already installed. This makes the ATOM LS in a solution especially flexible in front of others lithium batteries Fixed capacity, where any future expansion requires duplicating the initial investment.

The Smart BMS with active balance manages the status of each cell individually, avoiding load imbalances that would reduce the useful life of the whole, while the Life cycle of up to 6000 cycles to 0.5c and the Design life of 10 years They guarantee a stable performance throughout the life of photovoltaic installation. The 90% download depth (dod) It allows to take advantage of practically all the energy stored in each cycle, a data especially relevant against technologies such as the Gel batteries, which usually limit the download to rather lower percentages.

Its exclusive compatibility with inverters Afore by communication Can / rs485 ensures a direct and no-loss of efficiency in hybrid systems, perfectly complementing any installation with inverters hybrid that is already part of the client’s self-consumption system.

A system designed to grow: 1, 2 or 3 modules

The modular architecture of the ATOM LS allows installers and end users to choose exactly the ability they need today, knowing that they can expand it tomorrow. Starting from the base module of 5,12kwh, the system documented by the manufacturer allows us to combine 2 modules for 10.24kwh or 3 modules for 15.36kwh in one stack, and even 4 clusters in parallel To achieve capabilities of up to 61,44kWh in higher consumption facilities. This scalability is especially useful in projects where the initial budget is adjusted, but an increase in electricity consumption or the incorporation of new solar In the future.

Detailed technical characteristics (1 module – 5,12KWh)

Performance specifications:

Type of battery: Lifepo4
Modules: 1
Nominal capacity: 100ah
Energy: 5120Wh (5,12KWh)
Nominal voltage: 51.2v
Operating voltage range: 43.2V ~ 58.4V
End of charge voltage: 57.6V ~ 58.4V
Load voltage limit: 58.4v
Maximum continuous discharge current: ≤120A / 6KW
Peak discharge current: 120A max.
End voltage discharge: 43.2v
Recommended discharge depth (DOD): 90%
Lifecycle: 6000 cycles to 0.5c
Useful life design: 10 years

General Specifications:

Communication: CAN / RS485
Efficiency: 97%
Maximum cluster in parallel: ≤4 units
Discharge temperature range: -20 ° C ~ 60 ° C
Charging temperature range: 0 ° C ~ 50 ° C
Storage temperature range: -15 ° C ~ 40 ° C
Type of terminal: Fast connector
Case material: Spcc
Degree of protection: Ip65
Degree of protection against corrosion: C4
Auxiliary heating function: Optional
Dimensions (L x P): 600 x 167mm
Certifications: IEC 62619 / EC / UN38.3 / MSDS
Compatibility inverter: Afore

Frequently Asked Questions (FAQ)

1. Can I buy a single 5.12kwh module and expand later?
Yes. The ATOM LS is designed to grow with your needs: you can start with 1 module (5,12KWh) and add a second or third module in the future until it completes a stack of 15,36kwh, without having to replace the equipment already installed.

2. How many modules can I combine in total?
According to the Datasheet of the manufacturer, each stack supports up 3 modules (15,36kWh), and also the system allows you to connect Up to 4 clusters in parallel, reaching total capacities of up to 61.44kWh for higher consumption facilities.

3. With what inverters Is this lithium battery compatible?
It is compatible natively with inverters Afore, communicating through protocol Can / rs485. You can check the full range in Inverters solar To complete your installation.

4. What does the DOD of 90% mean in this model?
The 90% download depth (dod) Indicates the percentage of stored energy that can be used safely in each loading and unloading cycle, without compromising the useful life of lithium cells.

5. Is it suitable for outdoor?
Yes, thanks to your IP65 protection and corrosion resistance Class C4, This lithium battery can be installed both indoors and outdoor. You can expand technical information on installation in the Blog Tienda Solar, with purchase and content guides developed by experts.

Battery Voltage (V): + 48
Battery Energy (kWh): 5 – 6
