Victron BlueSolar MPPT 150/100 Solar Controller

Victron BlueSolar MPPT 150/100 Solar Controller

$451.55

Reference BS-MPPT-150/70-MC4

Victron BlueSolar MPPT 150/100 Solar ControllerVictron MPPT solar charge controller for 12V, 24V, 36V or 48V systems. Ultra-fast maximum power point tracking achieves up to 30% more energy than conventional controllers. For 1450W of solar panels in 12V systems and up to 5800W in 48V systems. Available in 2 input types for the PV field.

Connector

Clear

SKU: N/A Category: Solar Charge Controller Brand: Victron

Description

Victron BlueSolar MPPT 150/100 Solar Controller

The BlueSolar MPPT 150/100 controller from Victron is one of the most optimized controllers, both in the management of the battery charge and in the maximization of the energy extracted from the solar panel.

The sizing is simple, in 12V battery systems the recommended power is 1450W, if this is exceeded the controller will limit the power to 1450W. For 24V systems this value increases to 2900W, for 36V it reaches 4350W and for 48V it reaches 5800W.

You can use any model of photovoltaic solar panel satisfying:

The maximum open circuit voltage will not exceed 145V
The short-circuit current must be at most 70A. Greater intensity could damage the controller.
The photovoltaic voltage must be at least 5V more than the voltage of the battery to start, and 1V at least during operation.

Main features

Battery voltage: automatic detection of 12V / 24V / 36V / 48V
Nominal PV power: 1450W (12V), 2900W (24V), 4350W (36V), 5800W (48V)
Nominal load current: 70A
Size: Models Tr: 216 x 295 x 103 mm
Weight: 4,5 kg

Additional information

Connector	Connector MC4, Connector TR
