I-Topcon efficiency in compact format: TRINE VERTEX S + 510W

On Tienda Solar We present the Trina Vertex S + 510W (TSM-Neg18R.28), a module designed specifically to balance power and manageability. When using technology N-Type I-Topcon, Trina Solar He has achieved a panel that not only generates more energy from the first day, but maintains exceptional performance over the decades, surpassing standard monocrystalline modules.

Double glass design: armored reliability

The differential feature of the Vertex S + series is its structure of double glass. Unlike conventional panels with plastic back sheet, this model uses two glass layers that protect the cells from chemical degradation, moisture and mechanical wear. On Tienda Solar We recommend this panel for areas of high salinity or humidity, since its construction minimizes the appearance of microfixes and guarantees a Class A Fire Resistance.

More power by String and less degradation

The design of low voltage From Vertex S + 510W is a strategic advantage for installers. Allows you to connect a greater number of modules in the same series (String), optimizing the use of Network Connection Investors And reducing the cost of installation. In addition, being technology of n, degradation in the first year is just the 1%, with an annual fall of only the 0,4% for the next 29 years. This is translated into a 30-year power guarantee, ensuring that your investment in photovoltaic plates Be profitable to very long term.

Thermal performance and versatility

With a coefficient of temperature -0,29% / ° C., this panel render above the average in hot climates, ensuring that your lithium batteries Even even in the hours of greater radiation are loaded. Its optimized size makes it ideal for both large industrial buildings and for demanding residential facilities, adapting perfectly to diverse Structures for Solar Panels.

Technical specifications (STC)

• Maximum power (PMAX): 510w

• Efficiency of the module: 22,9%

• Maximum power voltage (VMP): 31,8v

• Maximum power current (imp): 16,02a

• Open circuit voltage (VOC): 38,3v

• Short circuit current (ISC): 16,97a

• Dimensions: 1961 x 1134 x 30 mm

• Weight: 26.7 kg

• Warranty: 25 years of product and 30 years of linear power.

Frequently Asked Questions (FAQ)

1. Why is the double glass better for my business in Tienda Solar? Reduces the risk of hot spots and offers much greater durability before external agents. In addition, its degradation is slower, which means that you will receive more kWh for each euro invested during the useful life of the system.
2. Is this 510W panel easy to install? Yes, your weight of 26.7 kg and its average size allow a simpler manipulation in covers than the panels over 600w, saving time in labor and facilitating anchor in Structures for inclined cover.
3. What maintenance recommends Tienda Solar? Like all high efficiency panels, keeping the clean surface is key. We recommend a cleaning with Fresh water and a soft cloth Especially after episodes of calima or suspension dust so as not to lose that 22.9% efficiency.
